Products

YOUFA-Top 500 Enterprises of China Industry Leading Brands.
-ISO9001, ISO14001, PED, TUV certified, Product carbon footprint certificate, ISO17025 CNAS lab

OD: 12-32mm
WT: 0.5-2.5mm
L: customizable

OD: 10-101.6mm
WT: 0.5-3.5mm
L: customizable

OD: 15-2,000mm
WT: 0.5-100mm
L: max 18m

OD: 10-630mm
WT: 0.5-3.5mm
L: max 18m

Austenitic Stainless Steel Pipe/Tube

Austenitic stainless steel has austenite as its primary phase at both elevated and room temperature. A stable austenite contains about 18% Cr, 8%-10% Ni and about 0.1% C. Cr-Ni austenitic stainless steel includes the most familiar stainless steel 18Cr-8Ni and the series of high Cr-Ni steel developed by increasing Cr and Ni content and adding elements such as Mo, Cu, Si, Nb, Ti, etc. Austenitic stainless steel is characterized by non-magnetic, high plasticity and ductility but lower strength. It can be only strengthened via cold working (by adding S, Ca, Se, Te and etc., austenitic stainless steel can have excellent machinability).



Grades

Standards

  • ASTM A249 Standard Specification for Welded Austenitic Steel Boiler, Superheater, Heat-Exchanger, and Condenser Tubes
  • ASTM A269 Standard Specification for Seamless and Welded Austenitic Stainless Steel Tubing for General Service
  • ASTM A312 Standard Specification for Seamless and Welded Austenitic Stainless Steel Pipes
  • ASTM A358 Standard Specification for Electric-Fusion-Welded Austenitic Chromium-Nickel Stainless Steel Pipe for High-Temperature Service and General Applications
  • ASTM A789 Standard Specification for Seamless and Welded Ferritic/Austenitic Stainless Steel Tubing for General Service
  • ASTM A790 Standard Specification for Seamless and Welded Ferritic/Austenitic Stainless Steel Tubing for General Service

(Super) Austenitic Stainless Steel Pipe/Tube

Super austenitic stainless steel is defined as Cr-Ni stainless steel with a Pitting Resistance Equivalent Number (PREN=[Cr]+3.3[Mo]+16[N])≥40%. Super austenitic stainless steel is mainly developed to solve the deficiency of pitting corrosion resistance, crack corrosion resistance and poor thermal stability of the original high molybdenum (>4%) Cr-Ni austenitic stainless steel under the harsh corrosion conditions containing Cl-.



Grades

Standards

  • ASME SA312 Standard Specification for Seamless and Welded Austenitic Stainless Steel Pipes
  • ASME SA269 Standard Specification for Seamless and Welded Austenitic Stainless Steel Tubing for General Service
  • ASME SA789 Standard Specification for Seamless and Welded Ferritic/Austenitic Stainless Steel Tubing for General Service
  • ASME SA790 Standard Specification for Seamless and Welded Ferritic/Austenitic Stainless Steel Tubing for General Service

(Super) Duplex Stainless Steel Pipe/Tube

Duplex stainless steel (DSS) is featured with structure of two phases (α and γ) and has characteristics of both ferritic and austenitic stainless steel. It has best corrosion resistance and high strength. In general, when the content of C is low, the content of Cr and Ni ranges from 18% to 28% and 3% to 10% respectively. Some steels also contain the alloy elements such as Mo, Cu, Nb, Ti and N, etc.

Grades

Standards

  • ASME SA789  Standard Specification for Seamless and Welded Ferritic/Austenitic Stainless Steel Tubing for General Service
  • ASME SA790  Standard Specification for Seamless and Welded Ferritic/Austenitic Stainless Steel Tubing for General Service
  • ASME SA928 Standard Specification for Ferritic/Austenitic (Duplex) Stainless Steel Pipe Electric Fusion Welded with Addition of Filler Metal

Corrosion & High Temperature Resistant Alloys Pipe

Inconel, Incoloy, Monel alloy steel pipes/tubes

Grades

Standards

  • ASME SB163 Standard Specification for Seamless Nickel and Nickel Alloy Condenser and Heat-Exchanger Tubes
  • ASME SB165 Standard Specification for Nickel-Copper Alloy Seamless Nominal Pipe and Tube
    ASME SB167 Standard Specification for Nickel-Chromium-Iron Alloys and Nickel-Chromium-Cobalt-Molybdenum Alloys Seamless Nominal Pipe and Tube
  • ASME SB407 Nickel-Iron-Chromium Alloy Nominal Pipe and Tube
  • ASME SB423 Nickel-Iron-Chromium-Molybdenum-Copper Alloy Nominal Pipe and Tube
  • ASME SB444 Standard specification for Nickel-Chromium-Molybdenum-Columbium Alloy and Nickel-Chromium-Molybdenum-Silicon Alloy Nominal Pipe and Tube
  • ASME SB622 Seamless Nickel and Nickel Cobalt Alloy Nominal Pipe and Tube
  • ASME SB668 UNS N08028Seamless Pipes
  • ASME SB690 Specification for Iron-Nickel-Chromium-Molybdenum Alloys Nominal Pipe and Tube
  • ASEM SB729 Seamless UNS N08020, UNS N08026, UNS N08024 Nickel Alloy Nominal Pipe and Tube
